NAS QNAP TS-253Be-2G

Extend NAS functionalities with the PCIe slot

With PCIe expansion, the TS-253Be provides flexibility in extending NAS functionality and potential applications. Install a QNAP QM2 card to provide M.2 SSD caching/10GbE connectivity, or use the TS-253Be as a wireless access point by installing a compatible wireless network card (ex. QNAP QWA-AC2600), or boost the USB connectivity of the TS-253Be by installing a USB 3.1 10Gbps card.

Intel® Celeron® J3455 quad-core 1.5GHz CPU with AES-NI Encryption

Powered by an Intel® Celeron® J3455 quad-core 1.5GHz processor (burst up to 2.3 GHz), 2GB/4GB DDR3L RAM (up to 8GB), dual Gigabit LAN ports, and supporting SATA 6Gb/s hard drives, the TS-253Be provides dependable performance of up to 225 MB/s read/write speeds. The TS-253Be features Intel® AES-NI hardware-accelerated encryption to drive transfer speeds of up to 225 MB/s with AES 256-bit encryption for both full NAS volumes and shared folders, boosting system performance while ensuring the security of sensitive data stored in the TS-253Be.

File Transfer (2 x GbE)

Windows Download

225 MB/s

Windows Upload

225 MB/s

File Transfer with Encryption (2 x GbE)

Windows Download

225 MB/s

Windows Upload

225 MB/s

Sequential Throughput (2 x 10GbE, 64KB)

Windows Download

659 MB/s

Windows Upload

648 MB/s

Tested in QNAP Labs. Figures may vary by environment.

Test Environment:
NAS：
OS：QTS 4.3.3
Volume: RAID 5; 4 x Intel S3500 240GB SSDs (SSDSC2BB240G4); QNAP LAN-10G2SF-MLX 2 ports 10GbE SFP+
Client PC:
Intel® Core™ i7-4770 3.40GHz CPU; DDR3L 1600Hz 16GB; WD 1TB WD10EZEX; Intel Gigabit CT (MTU 1500); Windows® 10 64-bit

Protect data with snapshots

Snapshots help protect your data by fully recording the NAS system state and metadata. If a file is accidentally deleted or modified, you can use snapshots to quickly restore the file to its previously-recorded state. QNAP snapshots are block-based and only record the changed data. Not only does this save storage space but also reduces the time required to back up and restore data. The TS-253Be supports up to 1,024 snapshots per NAS and up to 256 snapshots per volume or LUN.

Real-time video transcoding

Featuring advanced 9th-generation Intel® HD Graphics, the TS-253Be supports dual-channel 4K H.264/H.265 hardware decoding and real-time transcoding, allowing you to convert videos to universal file formats that can be smoothly played on multiple devices*. Therefore, you can easily share movies and videos stored on your NAS with family and friends for their enjoyment on a range of devices. The QNAP RM-IR004 remote control (sold separately) can be configured using QButton to customize the actions of individual buttons, providing a more convenient NAS experience.

*The TS-253Be’s hardware provides H.264 /H.265 hardware decoding, encoding and transcoding capabilities. However, playback quality may vary due to factors including playback software, file formats, system usage, and available bandwidth.

Multiple ways to enjoy videos

QNAP provides a wide range of multimedia applications for you to easily enjoy photos, music, and videos.

QVHelper allows users to stream media files or music playlists from a QNAP NAS to VLC player.

Qmedia allows music, photos and videos to be effortlessly streamed to Android TVs or set-top boxes.

Video HD is a free KODI add-on that combines KODI's streaming and video decoding capabilities and fully supports Video Station's features.

Multiply your productivity

The app-driven QTS operating system provides solutions for simplifying file backup, management, search, and more. With File Station you can view and manage your files not only from NAS but also from multiple storage devices; the OCR Converter allows you to extract text from images; Qfiling helps automate file organization, and Qsirch helps quickly find files.

Centralized File Management

Use File Station to directly access files on USB devices - including optical disc drives. Files from different devices can be easily viewed and managed on a single interface.

File Digitization

OCR Converter extracts text from images, helping to boost productivity and making it easier to find files.

Smart Filing

Qfiling automates file organization. Files are automatically archived into folders based on your settings.

Full-text Search

Qsirch quickly finds images, music, videos, documents, emails, and other files.

Multi-point backup and access

With integrated data backup, restoration and synchronization, Hybrid Backup Sync helps you easily backup or synchronize data on the TS-253Be to other QNAP NAS, USB storage (one touch copy) or cloud storage. With Qsync, you can also access your NAS files from PCs, laptops or mobile devices connected with the TS-253Be at any time.

NAS as a Multi-OS Platform

Virtualization Station and Container Station provide comprehensive solutions for creating virtualized environments to improve business IT infrastructure, workflows, and productivity.

Virtualization Station

Virtualization Station allows you to run multiple Windows®, Linux®, UNIX® and Android™ virtual machines on the TS-253Be. You can use Virtual Network Computing (VNC) through a browser to manage the VMs. Virtualization Station is ideal for organizations to run multiple applications on a single NAS.

Container Station

Container Station integrates LXC and Docker® lightweight virtualization technologies. You can download apps from the built-in Docker Hub® to easily import/export container apps and manage access control, enjoying the benefit of easy installation, transferability and high-efficiency.

Supports 360-degree panorama photos and videos

QNAP NAS now supports the popular 360-degree panorama recording format! By clicking the 360-degree panorama display button, these photos and videos will be displayed as 360-degree panorama media files. The QNAP mobile apps Qfile, Qphoto and Qvideo also support 360-degree format viewing.

Whole new QVR Pro surveillance solution

QNAP’s new QVR Pro surveillance solution allows you to arrange a dedicated, independent storage space for surveillance data on TS-253Be and leverage the advantages of scalability and storage manageability from QTS. With QVR Pro, camera management, storage space allocation, camera live view and playback become more easily. You can also use QVR Pro Client’s mobile app to monitor anytime, or use a USB webcam as an ONVIF network camera with the QUSBCam2 app.

Comprehensive surveillance solution for 24/7 monitoring

Surveillance Station provides an intelligent video management system to assist in managing real-time monitoring, video & audio recording and playback with a wide range of customizable settings to safeguard your physical environment. You can use the Vmobile mobile app to manage the monitored channels at anytime and anywhere, or install the Vcam mobile app to turn your device into a network camera to instantly record to your NAS.

3,000+

compatible IP cameras

4

free IP camera channels

40

expandable channels

QUSBCam2

record from USB webcams

Flexible and economical storage expansion

You need an easy solution to increase storage capacity when running out of space. QNAP provides several ways to expand your NAS storage as needed to accommodate data and business growth.

Upgrade RAID Capacity

Hot swap lower-capacity drives with larger-capacity drives so that your QNAP NAS can grow with your business.

Attach Expansion Enclosures

Connect a UX-800P or UX-500P expansion enclosure and use the QTS Storage & Snapshots Manager to easily handle NAS capacity expansion.

VJBOD

Use VJBOD (Virtual JBOD) to expand your storage capacity by using the unused storage of other QNAP NAS. Up to 8 QNAP NAS can be mounted as local disks on the TS-253Be.

Migrate to a New NAS

Install your NAS hard drives into a larger QNAP NAS and retain all your existing data and configurations.
